Product Features:
- Cobalt-free LiFePO4 chemistry; optional fire extinguisher
- Parallel up to 63 units; modular rack design
- 1C continuous discharge; 6,000+ cycles
- Module-level auto-balancing; works with 20+ inverters
- AC coupled for new or retrofit installs
- No thermal runaway, heat, or toxic cooling required
- Built-in BMS with breaker on/off switch
- UL-standardized Tier One A+ cells
- Remote upgrades; WiFi/Bluetooth app monitoring
Specifications:
- Battery Type: LiFePO4
- Nominal Voltage: 51.2V
- Nominal Capacity: 5.12kWh
- Usable Capacity: 4.608kWh
- Cell & Method: 16S1P
- Dimensions (W×H×D): 538×483(442)×136 mm
- Weight: 46 kg
- Discharge Voltage: 47V
- Charge Voltage: 55V
- Charge Rate (Current / Power): 50A / 2.56kW
- Max Charge (Current / Power): 80A / 4.096kW
- Peak Charge (Current / Power): 110A / 5.632kW
- Discharge Rate (Current / Power): 100A / 5.12kW
- Max Discharge (Current / Power): 120A / 6.144kW (1s)
- Peak Discharge (Current / Power): 150A / 7.68kW (1s)
- Communication: RS232, RS485, CAN, WiFi (Optional), Bluetooth (Optional)
- Depth of Discharge: 90%
- Expansion: Up to 63 units in parallel
-
Working Temperature: Charge 0
55℃ / Discharge -2055℃ - Storage Temperature: 0~33℃
- Short Circuit Current / Duration: 350A, Delay 500μs
- Cooling Type: Natural
- Protection Level: IP20
- Monthly Self-discharge: ≤ 3%
- Humidity: ≤ 60% ROH
- Altitude: < 4000m
- Warranty: 10 years
- Design Life: > 15 years (25℃)
- Cycle Life: > 6000 cycles (25℃)
-
Certification: UN38.3
