- Total Energy Capacity: 100 kWh
- 80% DoD Energy: 80 kWh
- 90% DoD Energy: 90 kWh
- Current Capacity: 2,000 Ah
- Max. Continuous Charge and Discharge Current: 2,000 A
- Max & Cont. Charge and Discharge Power: 100 kW
- Nominal Voltage: 52 V
- Max. Inverter Capacity: 90 kVA
- Total Weight: 883 kg
- Dimensions: Height - 1,550 mm, Depth - 370 mm, Length - 1,261 mm
- DC Connection: Fly Leads, 3×120 mm²
- Round Trip Efficiency: 96-97%
- Enclosure: 3mm thick Aluminium, powder coated, tamper proof, indoor use
- External Interface: CAN Bus
- On-board Management: Comprehensive battery management system and internal trip protection
- Human Interfaces: On and Off Buttons, State of Charge Display (0 to 100%), Error light, Error Reset Button, USB plug for Programming and data access with PC, main breaker
- Protection: Shunt Trip Circuit Breaker sized to suit max current, can be tripped by BMS if critical fault, manual reset. Protection for overcurrent, cell under and over voltage, temperature, weak cell detection and other critical events
- Battery Chemistry: Lithium Iron Phosphate (LiFePO4)
- Cell Form Factor: Large Format heavy-duty prismatic cells of 200Ah each and 3,2V nominal voltage, fully sealed in plastic casing with laser electrode connections
- Battery Cooling: Natural Convection (heat generation is negligible inside the battery)
- Suitable Ambient Temp: 0°C to +35°C
- Extreme Operating Temp: -20°C to +60°C
- Warranty: 10 years or 4,000 cycles for average 80% DoD, and max 90% DoD
- Service Life – Cycles & Years: >16 years (>5,500 cycles) expected life at 80% DoD per cycle, >20 years (>7,500 cycles) at 50% DoD
Note: Delivery Not Included - Once your order has been placed, our sales team will contact you to confirm delivery fees.
