The Fronius SYMO 15.0-3-M Advanced Lite + DC OVP is a high-performance, three-phase grid-connected inverter designed for medium to large PV systems. With a wide input voltage range, dual MPP trackers, and a peak DC input of 22.5 kW, it offers maximum flexibility in PV array configuration. Built with advanced safety features including DC overvoltage protection, this transformerless inverter ensures reliable and efficient operation even in challenging environmental conditions. Its IP65 protection rating and robust cooling system make it suitable for both indoor and outdoor installations.
Specifications:
Input Data
- Number of MPP Trackers: 2
- Max. Input Current (Idc max): 12 / 12 A
- Max. Short Circuit Current (Module Array): 24 / 24 A
- DC Input Voltage Range: 80 – 1000 V
- Feed-in Start Voltage: 80 V
- Nominal Input Voltage: 710 V
- MPP Voltage Range: 240 – 800 V
- Usable MPP Voltage Range: 80 – 800 V
- Number of DC Connections: 2 + 2
- Max. PV Generator Power (Pdc max): 7.5 kWpeak
Output Data
- AC Nominal Output (Pac,r): 5000 W
- Max. Output Power (Pac max): 5000 VA
- AC Output Current (Iac nom): 21.7 A
- Grid Connection: 1~ NPE 220/230 V
- AC Voltage Range: 180 – 270 V
- Frequency: 50 / 60 Hz
- Frequency Range: 45 – 65 Hz
- Total Harmonic Distortion: <3% @Pnom
- Power Factor Range (cos φac,r): 0.85 – 1 (inductive/capacitive)
General Data
- Dimensions (W x H x D): 432.5 x 642.5 x 205.5 mm
- Weight (Net / Packaged): 19.25 kg / 25.8 kg
- Degree of Protection: IP65
- Protection Class: 1
- Overvoltage Category (DC / AC): 2 / 3
- Night-Time Consumption: < 1 W
- Inverter Design: Transformerless
- Cooling Method: Regulated air cooling
- Installation Location: Indoors and outdoors
- Ambient Temperature Range: -40°C to +55°C
- Permitted Humidity: 0 – 100%
- Max. Altitude: 4000 m
- Connection Technology
- DC Terminals: 4x DC+ and 4x DC- screw terminals (2.5 – 16 mm²)
- AC Terminals: 3-pin AC screw terminals (2.5 – 16 mm²)
- Certifications & Compliance
- Standards: DIN V VDE 0126-1-1/A1, IEC 62109-1/-2, IEC 62116, IEC 61727, AS 4777-2, AS 4777-3, G98/1, G99/1, CEI 0-21, VDE AR N 4105
- Sound Emissions: 55 dB(A)
- Interference Emission Class: B
