Product Features:
- Supports AC & PV input
- Integrated MPPT for optimal solar charging
- 4000W AC heating rated power
- No need to change existing geyser element
- Ideal for household retrofit geysers
- Suitable for 100% off-grid installations
- Large LCD display for real-time monitoring
- Integrated WiFi for smart control
- Built-in temperature sensor for accurate heating
-
IP65-rated for dust and water resistance
Specifications
Photovoltaic Characteristics
- Solar Max. Input Power: 4000 W
- Solar Input Current: ≥ 20 A
- Solar Input Voltage Range: 160–350 Vdc
- MPPT Operating Voltage Range: 120–340 Vdc
- MPPT Efficiency: ≥ 99%
- Solar Heating Output Voltage Range: 0–260 Vac
- Solar Heating Output Current Range: ≤ 20 A
AC Characteristics
- AC Heating Rated Power: 4000 W
- AC Rated Voltage: 230 Vac
- AC Working Voltage Range: 180–260 Vac
- AC Rated Current: ≤ 20 A
Load Requirement
- Load: ≤ 230V / 4000W
- Resistance Value: ≥ 13 Ω
Machine Characteristics
- LCD Display: Yes
- Max Water Temperature: 30–80°C (settable)
- WiFi: Yes
- Temperature Sensor: Yes (4M)
- Machine Dimensions: 258 × 190 × 84.5 mm
- Package Dimensions: 305 × 244 × 162 mm
- Net Weight: 2.8 kg
- Gross Weight: 3.1 kg
- Ingress Protection: IP65
