Reyee Dual Band WiFi 6 3000Mbps Gigabit Outdoor AP

Reyee Dual Band WiFi 6 3000Mbps Gigabit Outdoor AP

The RG-RAP62X from Reyee delivers high-performance outdoor connectivity with its IP65-rated compact design featuring integrated antennas. This WiFi 6 access point offers dual-band capability with impressive throughput—573Mbps on 2.4GHz and 2401Mbps on 5.8GHz bands, totaling 2974Mbps. It incorporates 2x2 MU-MIMO technology, Gigabit Ethernet connectivity, and supports standalone portal functionality with Layer 3 roaming. Integration with Ruijie's cloud service enables streamlined remote management, while auto-discovery and QR code scanning facilitate effortless deployment into new or existing network infrastructures.

Product Features:

• Dual-band AX3000 Wi-Fi 6 access point for indoor and outdoor environments
• Supports both wall-mount and pole-mount installations
• IP65-rated weatherproof design for reliable outdoor performance
• Built-in omnidirectional antennas with 6.5 dBi gain (5 GHz) and 4.0 dBi gain (2.4 GHz)
• Supports Reyee Mesh for seamless wireless mesh networking
• Compatible with cloud-based and local management via Ruijie Reyee App and Ruijie Cloud
• Enhanced roaming capabilities with support for AI Roaming and 802.11k/v/r
• Secure access features including WPA3, WPA2, and 802.1X authentication
• Standalone captive portal for user access control
• Supports up to 110 recommended clients with 8 SSIDs per access point
• Surge protection up to 4 kV and ESD protection up to 15 kV


Specifications:

• Wi-Fi Protocols:
  • 2.4 GHz: IEEE 802.11b/g/n/ax
  • 5 GHz: IEEE 802.11a/n/ac/ax
• Max Data Rates:
  • Total: 2974 Mbps
  • 2.4 GHz: 573 Mbps
  • 5 GHz: 2401 Mbps
• Channel Width:
  • 2.4 GHz: 20/40 MHz
  • 5 GHz: 20/40/80/160 MHz
• Spatial Streams:
  • 2x2 MIMO for both 2.4 GHz and 5 GHz
• Max Transmit Power: 23 dBm (both bands)
• Ports: 1 x 10/100/1000BASE-T (PoE supported)
• Power Supply: 802.3af/at PoE; power consumption < 16 W
• Physical Dimensions: 200 x 70 x 35 mm
• Weight: ≤ 0.4 kg
• Mounting Options: Wall or pole mount
• Operating Temperature: –30°C to +65°C
• Ingress Protection: IP65 rated
• Max Clients Supported: 110 (AX), 40 (AC)
• Memory: 512 MB RAM
• Flash Storage: 128 MB
• Management: Web interface, Ruijie Cloud, Ruijie Reyee App
• Security: WPA3, WPA2, PSK, OWE, 802.1X, VLAN support
• Roaming Support: Layer 2 and 3 roaming, 802.11k/v/r, AI Roaming
• Color: Warm White
