SRNE 10KW Off Grid Inverter

SRNE 10KW Off Grid Inverter

Regular price R 18,078.00 ZAR
Regular price Sale price R 18,078.00 ZAR
Sale Sold out
Tax included. Shipping calculated at checkout.

SRNE 10KW Off Grid Inverter - SF48100S200-H

SRNE 10KW Off-Grid Inverter, a high-efficiency powerhouse designed for seamless performance. With dual MPPT technology reaching up to 99.9% efficiency and supporting 22A PV input current, it accommodates high-power modules. Producing top-notch pure sine wave AC power with a 10kW load capacity, this inverter ensures households' diverse energy needs are met.

Its industrial yet modern design guarantees durability and aesthetics. Installation is easy, and user-friendliness is a priority. The inverter's versatility shines with a Solar Charger Controller. Supporting up to 200A charging current and Li-ion battery BMS communication. With exclusive Li-ion battery BMS dual activation and a time-slot function for peak-valley tariff savings, the SRNE 10KW Off-Grid Inverter is the all-in-one solution for efficient, reliable, and cost-effective power.

Product Features:

  • Dual MPPT with up to 99.9% efficiency
  • Up to 22A PV input current perfect for high-power modules
  • Industrial design with a modern aesthetic look
  • Easy to install and simple to use
  • 360 degrees of security from hardware to software
  •  Time-slot function to save cost with peak-valley tariff l

Specifications:

  • Inverter Output:
    • Rated Output Power: 10,000W
    • Max.Peak Power: 20,000W
    • Rated Output Voltage: 230Vac(single-phase L/N/PE )
    • Switch Time: 10ms(typical)
  • Battery:
    • Battery Type: Li-ion / Lead-Acid / User Defined
    • Rated Battery Voltage: 48Vdc
    • Voltage Range: 40~60Vdc
    • Max.MPPT Charging Current: 200A
    • Max.Mains/Generator Charging Current: 120A
    • Max.Hybrid Charging Current: 200A
  • PV Input
    • Num. of MPP Trackers: 2
    • Max.PV array power: 5,500W + 5,500W
    • Max.input current: 22A + 22A
    • Max.Voltage of Open Circuit: 500Vdc + 500Vdc
    • MPPT Voltage Range: 125~425Vdc
  • General
    • Dimensions: 620*445*130mm
    • Weight: 27kg
    • Noise: <60dB
    • Cooling Method: Internal Fan
    • Warranty: 2 Years



Important

Please ensure that the battery bank's power and storage capacity is sufficient for the inverter and installation requirements.

This product must be installed by a qualified electrician/technician. All installations must adhere to local wiring regulations and standards. Crystal Communications and its Supplier will not be held liable for any product malfunctions as a result of incorrectly installed systems.

Technical specifications and general features are provided on our website, however, as individual needs and requirements may differ, it is recommended that our sales team is contacted for any specific questions before a purchase is made to ensure that the item being purchased will satisfy your requirements.
