Victron BlueSolar PWM-Pro Charge Controller 12/24V-10A

Victron BlueSolar PWM-Pro Charge Controller 12/24V-10A

R 451.00
R 451.00
Sale Sold out
Tax included. Shipping calculated at checkout.

Victron BlueSolar PWM-Pro Charge Controller 12/24V-10A

The BlueSolar PWM-Pro and PWM-Light charge controllers provide reliable and efficient solar battery charging with built-in load control and protection features. The PWM-Pro offers advanced programmability including lighting control, three-stage charging, and integrated battery monitoring, while the PWM-Light delivers straightforward, easy-to-use functionality with essential protections and timer settings.

Product Features:

  • Fully programmable lighting control and battery charging
  • Three-stage battery charging (bulk, absorption, float)
  • Integrated battery monitor (requires Remote Panel)
  • Load output with low voltage disconnect and manual control
  • Overload, short circuit, and reverse polarity protection
  • Optional external temperature sensor
  • Day/night timing options

PRODUCT SPECIFICATIONS

- Battery voltage: 12/24V
- Rated charge current: 10A
- Automatic load disconnect: Yes
- Maximum solar voltage: 28V / 55V
- Self-consumption: < 10mA
- Load output: Manual control + low voltage disconnect

Protection:
- Battery reverse polarity (fuse)
- Output short circuit
- Over temperature

- Temperature compensation: -30 mV / °C resp. -60 mV / °C (if temperature sensor installed)
- 0 Grounding: Common positive
- 0 Operating temp. range: -20 to +50°C
- 0 Humidity (non-condensing): Max 98%

DEFAULT SETTINGS:
- Absorption charge: 14.4V / 28,8V
- Float charge: 13.8V / 27,6V
- Equalization charge: 14,6V / 29,2V
- Low voltage load disconnect: 11,1V / 22,2V
- Low voltage load reconnect: 12,6V / 25,2V

ENCLOSURE:
- Terminal size: 4mm²
- Protection category: IP30
- Weight: 0,13kg
- Dimensions (h x w x d): 138x70x37 mm /5.4x2.7x1.4 inch

IMPORTANT NOTICE

Please ensure that the battery bank's power and storage capacity is sufficient for the inverter and installation requirements.

Technical specifications and general features are provided on our website, however, as individual needs and requirements may differ, it is recommended that our sales team is contacted for any specific questions before a purchase is made to ensure that the item being purchased will satisfy your requirements.

The images shown are for illustration purposes only and may not be an exact representation of the product.

Crystal Communications (Pty) Ltd may not have all the specific items or quantities of stock you have requested. Our dedicated Customer Service Team will use our extensive network to try to source the stock for you ASAP. You will be notified within 24 hours if we cannot source the required item, and a full refund will be processed on your order. Should you wish to contact us directly, please call 0118670488 or email sales@crystalcom.co.za
