Victron EasySolar-II 48/5000/70-50 MPPT 250/100 GX

The EasySolar-II GX combines an MPPT Solar Charge Controller, an inverter/charger and control hub in one enclosure. The product is easy to install, with a minimum of wiring.

Features:

• All-in-One Unit: Combines a MultiPlus-II inverter/charger, SmartSolar MPPT charge controller, and GX control device
• Prewired for Easy Installation: Simplifies setup and reduces wiring time and costs
• Integrated Display & Wi-Fi: Monitor system parameters and configure settings via display or smartphone
• SmartSolar MPPT Controller: Efficient solar charging with parallel DC output wiring
• GX Device Connectivity: Includes USB, Ethernet, VE.Direct, and BMS-Can interfaces
• Remote Monitoring: Compatible with the Victron VRM app (iOS & Android) for full system control

 Specifications:

INVERTER/CHARGER

• PowerControl & PowerAssist: Yes

• Transfer switch: 50 A

• Maximum AC input current: 50 A

• Auxiliary output: 50 A

INVERTER

• Input voltage range: 38 – 66 V

• Output voltage: Output voltage: 230 VAC ± 2 % Frequency: 50 Hz ± 0,1 %   (1)

• Cont. output power at 25°C: 5000 VA / 4000 W

• Cont. output power at 40°C / 65°C: 3700 W / 3000 W

• Maximum apparent feed-in power: 4400 W / 5000 VA

• Peak power: 9000 W

• Maximum efficiency: 96%

• Zero load power: 18 W

• Zero load power in AES mode: 12 W

• Zero load power in Search mode: 2 W

CHARGER

• AC input voltage range: Input voltage range: 187-265 VAC Input frequency: 45 – 65 Hz

• Input frequency: 45 – 65 Hz

• Charge voltage ‘absorption’: 57.6 V

• Charge voltage ‘float’: 55.2 V

• Storage mode: 52.8 V

• Maximum battery charge current: 70 A

• Battery temperature sensor: Yes

• Programmable relay (5): Yes

• Protection (2): a – g

• VE.Bus communication port: For parallel and three phase operation, remote
• monitoring and system integration

• General purpose com. port: Yes, 2x

SMARTSOLAR CHARGE CONTROLLER

• Model: MPPT 250/100-Tr

• Maximum output current: 100 A

• Maximum PV power: 5800 W

• Maximum PV open circuit voltage: 250 V

• Self-consumption: 20 mA
• Charge voltage ‘absorption’, default: 57.6 V

• Charge voltage ‘float’, default: 55.2 V

• Protection (2): a – e

GENERAL

• Interfaces: BMS-Can, USB, Ethernet, VE.Direct, Wi-Fi

• Remote on-off: Yes

• Operating temp. range: -20 to +45 °C (fan assisted cooling) Max. altitude 2000 m

• Humidity (non-condensing): Max. 95%

ENCLOSURE

• Material & Colour: aluminium (Blue RAL 5012)

• Protection class: IP21

• Battery-connection: M8 bolts

• PV connection: M6 bolts

• AC connection: Screw terminals 13 mm² (6 AWG)

• Weight: 38.6 kg

• Dimensions h x w x d mm: 604 x 323 x 253
