The Inverter RS Smart Solar is a high-performance 48VDC, 6kVA inverter combined with a 4kW high-voltage MPPT solar charger (80–450VDC), designed for efficient off-grid solar systems. Weighing just 11 kg, it delivers excellent efficiency, low standby consumption, and ultra-quiet operation. With built-in Bluetooth, a clear onboard display, and VE.Can and VE.Direct ports for full connectivity and remote monitoring, it's a compact powerhouse for reliable solar energy use.
Features:
- All-in-One Design: Combines a 48VDC, 6kVA pure sine wave inverter with a high-voltage 80–450VDC, 4kW MPPT solar charger.
- Compact & Lightweight: High-frequency design reduces weight to only 11 kg.
- High Efficiency: Optimized for off-grid systems with minimal energy loss.
- Low Standby Power Consumption: Designed for energy-saving performance.
- Quiet Operation: Minimal fan noise during low to medium loads.
- Integrated Display: Shows real-time data for inverter, battery, and solar input.
- Bluetooth Connectivity: Monitor and configure via the VictronConnect app.
- Remote Monitoring Ready: Includes VE.Can and VE.Direct ports for connection to GX devices or GlobalLink 520.
- Flexible PV Input: Supports 80–450VDC solar array, ideal for efficient installations.
- Generator Compatible: Can be paired with an external battery charger to support generator integration.
Specifications:
Inverter Specs
- DC input voltage range: 38–62 VDC
- AC output voltage: 230 VAC ± 2%
- Output frequency: 50 Hz ± 0.1%
- Maximum continuous inverter current: 25 A AC
- Continuous output power at 25 °C: 4,800 W at 46 VDC, 5,300 W at 52 VDC
- Continuous output power at 40 °C: 4,500 W
- Continuous output power at 65 °C: 3,000 W
- Peak power: 9 kW for 3 seconds; 7 kW for 4 minutes
- Short-circuit output current: 45 A
- Max AC output overcurrent protection: 30 A
- Maximum efficiency: 96.5% at 1 kW load; 94% at 5 kW load
- Zero-load power consumption: 20 W
- Low battery shutdown voltage: 37.2 V (adjustable)
- Low battery restart voltage: 43.6 V (adjustable)
MPPT Solar Charger Specs
- Maximum PV voltage: 450 V
- MPPT voltage range: 65–450 V
- Start-up voltage: 120 V
- Max operational PV input current: 18 A
- Max PV short-circuit current: 20 A
- Maximum DC solar charging power: 4,000 W
- Earth leakage trip level: 30 mA
- Isolation fail detection: 100 kΩ before start-up
AC Charger Specs
- Programmable charger voltage range: 36–60 V
- Absorption charge voltage (default): 57.6 V (adjustable)
- Float charge voltage (default): 55.2 V (adjustable)
- Maximum AC charge current: 88 A at 57.6 V
- Combined charger current (AC + PV): 100 A
- Battery temperature sensor: Included
- Battery voltage sensing: Yes
Interfaces & Features
- Parallel and 3-phase operation: Up to 12 units in parallel; 4 units per phase for 3-phase setups
- Programmable relay: Yes
- Communication ports: VE.Direct, VE.Can, Bluetooth
- Bluetooth: 2402–2480 MHz frequency, 4 dBm output power
- General I/O: 2 analog/digital ports; remote on/off supported
