The Victron Orion 12/24-10 is a compact and efficient DC-DC converter that delivers stable 24 V output from a 12 V input. Designed for automotive, marine, and industrial applications, it is ideal for buffering or charging batteries while providing reliable power to sensitive electronics.
Specifications:
- Input voltage range (V): 9–18
- Under voltage shutdown (V): 8
- Under voltage restart (V): 10
- Output voltage adjustment range (V): yes
- Output voltage (V): Adjustable 20-30V F set 26,4V
- Efficiency (%): 95
- Suitable to buffer-charge a battery: Yes
- Can be connected in parallel: Yes
- Continuous output current (A): 10
- Max. output current (A): 20
- Fan assisted cooling (temp. controlled): No
- Galvanic isolation: No
- Off-load current: < 15mA
- DC connection: Faston tabs 6.3 mm
- Operating temperature range (full load): -20 to +55°C
- Protections: Overload, short circuit, and reverse polarity protection
- Weight (kg): 0,4 (0.9 lbs)
- Dimensions (h x w x d in mm / inches): 45x90x125 (1.8x3.5x4,5)
- Standards
- Safety: EN 60950-6-3, EN 50121-4
- Emission: EN 61000-6-2, EN 61000-6-1, EN 55014-2
- Immunity: EN 61000-6-2, EN 61000-6-1, EN 55014-2
