The Victron Orion 24/12-25A is a high-efficiency DC-DC converter engineered to deliver stable 12 V output from a 24 V input. Compact, reliable, and adjustable, it is ideal for automotive, marine, and industrial applications where efficient battery charging and power conversion are required.
Specifications:
- Input voltage range (V):18-35
- Under voltage shutdown (V):14
- Under voltage restart (V):18
- Output voltage adjustment range (V): yes
- Output voltage (V): Adjustable 10–15V F set 13,2V
- Efficiency (%): 96
- Suitable to buffer-charge a battery: Yes
- Can be connected in parallel: Yes
- Continuous output current (A): 25
- Max. output current (A): 35
- Fan assisted cooling (temp. controlled): No
- Galvanic isolation: No
- Off-load current: < 15mA
- DC connection: Faston tabs 6.3 mm
- Operating temperature range (full load): -20 to +55°C
- Protections: Overload, short circuit, and reverse polarity protection
- Weight (kg): 0,7 (1.55 lbs)
- Dimensions (h x w x d in mm / inches): 65x88x160 (2.6x3.5x6.3)
- Standards
- Safety: EN 60950-6-3, EN 50121-4
- Emission: EN 61000-6-2, EN 61000-6-1, EN 55014-2
- Immunity: EN 61000-6-2, EN 61000-6-1, EN 55014-2
