The Orion-Tr 24/12-30A DC-DC converter is a high-efficiency, reliable power solution for automotive, marine, and industrial applications. Using synchronous rectification, it delivers over 95% efficiency at full load, ensuring minimal energy loss. With IP43 protection when installed with screw terminals oriented downward, the unit is built to withstand challenging environments. Its easy-to-use screw terminals allow fast installation without the need for special tools, making it a convenient and robust choice for your power conversion needs.
Features:
- High Efficiency: Synchronous rectification provides over 95% full load efficiency.
- IP43 Protection: Safeguards the unit when mounted with screw terminals facing downward.
- Easy Installation: Screw terminals require no special tools.
-
Reliable Performance: Ideal for automotive, marine, and industrial applications.
Specifications:
- Input Voltage Range: 18–35 V
- Output Voltage: 12.7 V
- Efficiency: 95 %
- Continuous Output Current: 5 A
- Maximum Output Current: 7 A
- Galvanic Isolation: No
- Off-Load Current: < 20 mA
- Operating Temperature Range: -20°C to +55°C (derate 3% per °C above 40°C)
- DC Connection: Screw terminals
- Maximum Cable Cross-Section: 3.3 mm² (AWG12)
- Weight: 0.09 kg (0.20 lbs)
- Dimensions (HxWxD): 53 × 51 × 27 mm (2.1 × 2 × 1.1 in)
- Standards – Safety: EN 60950
- Standards – Emission: EN 61000-6-3, EN 55014-1
- Standards – Immunity: EN 61000-6-2, EN 61000-6-1, EN 55014-2
-
Automotive Directive: ECE R10-4
