The Orion-Tr 12/24-2.5A is a compact, high-efficiency isolated converter with a remote on/off terminal, ideal for converting 12 V to 24 V systems. Designed for easy installation, it offers reliable performance with short-circuit and high-temperature protection.
Features:
- Remote on/off control
- Short-circuit proof, parallelable
- High-temperature protected
- IP43 dust and splash resistant
- Screw terminal connections, no special tools needed
- Non-replaceable input fuse (12 V/24 V models)
- Adjustable output voltage (not for battery charging)
Specifications:
- Input Voltage Range: 16–35 V
- Under Voltage Shut Down: 14 V
- Under Voltage Restart: 15 V
- Nominal Output Voltage: 48.2 V
- Output Voltage Adjust Range: 40–60 V
- Output Voltage Tolerance: ±0.2 V
- Output Noise: 2 mV rms
- Continuous Output Current (25 °C): 2.5 A
- Maximum Output Current (10 s): 3 A
- Short Circuit Output Current: 19 A
- Continuous Output Power at 25 °C: 120 W
- Continuous Output Power at 40 °C: 115 W
- Efficiency: 88 %
- No Load Input Current: <120 mA
- Current Consumption (Remote Disabled): <200 µA
- Galvanic Isolation: 200 V DC between input, output, and case
- Operating Temperature Range: -20 °C to +55 °C (derate 3 % per °C above 40 °C)
- Humidity: Max 95 % non-condensing
- DC Connection: Screw terminals
- Maximum Cable Cross-Section: 6 mm² (AWG10)
- Weight: 0.42 kg (1 lb)
- Dimensions (HxWxD): 100 × 113 × 47 mm (4.0 × 4.5 × 1.9 inches)
-
Standards:
- Safety: EN 60950
- Emission: EN 61000-6-3, EN 55014-1
- Immunity: EN 61000-6-2, EN 61000-6-1, EN 55014-2
-
Automotive Directive: ECE R10-5
